KD-T711BT

Display

Display Type

VA LCD Display

LCD Color

White

Key Color

Blue

Music Sync. Effect

Yes

Spanish Text Display Compatible

Yes

French Text Display Compatible

Yes (Canadian French)

Auto Dimmer

Yes

Brightness Control

Yes

Media Playback

MP3 Compatible with Tag

CD/USB

WMA Compatible with Tag

CD/USB

WAV Compatible with Tag

USB

AAC Compatible with Tag

CD/USB

FLAC Compatible with Tag

USB ( Up to 96kHz/24bit )

Bluetooth Control

Built-in Bluetooth[1]

Yes (Ver 4.2, Wired-Mic included)

Hands Free Call

Yes (HFP 1.7.1)

2 Phones Full-Time Connection

Yes

Audio Streaming & Control (A2DP, AVRCP)

Yes (AVRCP 1.6.1)

Supported Audio Formats

AAC / SBC

5 BT-Audio Connection [JVC Streaming DJ]

Yes

Voice Dialing (voice recognition compatible mobile phone required)

Yes

Phone Book Access Profile (PBAP)

Yes

iPhone & Android Automatic Pairing

Yes (iPhone only)

Low Battery Information

Yes

Android Control

Android Music Playback

Yes (via Bluetooth(R))

iPod/iPhone Control

iPod/iPhone Music Playback

Yes (via USB or Bluetooth(R))

Amazon Alexa

Amazon Alexa Compatible

Yes

USB

Position

Front

USB Power Supply

Yes (1.5A)

Drive Change Mode for Mass Storage Class

Yes

Inputs and Outputs

AUX Input

1 (Front)

Line Output Terminals (Pair)

1 Pair (Rear/Subwoofer Selectable)

Pre-Output Level

2.5V

Subwoofer Output with Level/Frequency Control

Yes (Level -50 to +10)

Subwoofer Output Level

2.5V

Tuner

Radio Data Broadcast System (RBDS)

Yes

Preset Stations

18FM + 6AM

Strong Station Memory (for FM)

Yes

Tuner Preset Memory (for power disconnection)

Yes

FM

Frequency Range (Frequency Step)

87.9 - 107.9MHz (200kHz)

AM

Frequency Range (Frequency Step)

530 - 1,700kHz (10kHz)

Audio

Maximum Power Output

50W x 4 / 50W x 2 +Subwoofer (4 ohms) 50W x 1

Full Bandwidth Power (at less than 1%THD)

22W x 4

Subwoofer Direct Connection (Mono Lch)

Yes

EQ

Yes (13-Band Graphic EQ)

Preset EQ

Yes (11-Preset)

Bass Boost

Yes

Loudness Control

Yes

High-Pass Filter/Low-Pass Filter

Yes/Yes

K2 Technology

Yes

Time Alignment

Yes

Space Enhancement

Yes

Sound Response

Yes

Sound Lift

Yes

Volume Link EQ

Yes

General

Back Up Memory

Yes

Detachable Face Panel

Yes

Wireless Remote Control

Yes

Steering Remote Control Ready

Yes

Remote Control Application

Yes

Dimensions (W x H x D)

Installation Size

7-3/16" x 2-1/8" x 6-3/16" (182 x 53 x 156mm)

Weight

2.6 lbs. (1.2kg)

Unit weight in individual package

3.31 lbs. (1.5kg)
