iTK-C3X

CROSSOVER 3 WAY

FOR MID, HI OR SUBWOOFER PURPOSE

MAX OUTPUT LEVEL : 9.9 volts

SIGNAL BOOST / CUT : 13 dB

FREQUENCY RESPONSE : 10 - 50,000 Hz

THD TOTAL HARMONIC DISTORTION  > 0.015%

CHANNEL SEPARATION > 80

Selectable 12dB front and rear crossover with X1 OR X20 MULTIPLIER OPTION ON FIRST CHANNEL

LOW PASS OUTPUT : Selectable 12dB low-pass output for customizing the subwoofer amplifier system

PHASE SHIFTS Phase Inverter : Positioning switch 180 degrees shifts subwoofer output signals 180 degree out-of-phase relative to front and rear output signals

PRODUCT WEIGHT : 2.05 LBS

 PRODUCT DIMENSIONS : 7.80" D x 6.55" W x 1.80" H
